Playwright + Temporary Email API: Full E2E Auth Flow Testing

The Problem with Testing Email Auth Flows

Most Playwright suites stop at the form submission. The test fills the email field, clicks Submit, asserts a success banner, and calls it a day. But the auth flow doesn't end there — it ends when the user clicks the link in their inbox. That second half is invisible to your test.

The common workarounds all have the same failure mode in disguise:

• Mocking the email sender — you assert that sendEmail() was called, not that an email was received, rendered correctly, and contains a working link.
• Shared test inboxes — two parallel CI runs both register and poll the same inbox. The first email gets consumed by whichever test polls first. Flaky tests guaranteed.
• Hardcoded OTP bypass routes — test backdoors that sooner or later end up in a production build.
• Mailhog / Mailpit — one more container to deploy, a different API surface from production, and zero validation of your real SMTP path.

The issue isn't test tooling. It's the assumption that email delivery is a side effect you can safely skip or stub. In practice, your verification link can be malformed, your SMTP credentials can expire, your template can break — and a mocked test will pass through all of it.

---

What We Will Build

By the end of this article you will have a fully working TypeScript Playwright test that:

1. Creates a temporary inbox via the uncorreotemporal.com API
2. Submits a signup form using that inbox address
3. Polls for the incoming email with a configurable timeout
4. Extracts the OTP code or verification link from the message body
5. Completes the auth flow inside Playwright
6. Cleans up the inbox in teardown

The test uses real SMTP delivery — your application sends to the temporary inbox exactly as it would send to a real user. No interceptors, no stubs.

---

Architecture Overview

[Your App] ──signup form──► [FastAPI / Node backend]
                                    │
                              sends real email via SMTP
                                    │
                                    ▼
                         [uncorreotemporal.com SMTP receiver]
                                    │
                               stores message
                                    │
                  ┌─────────────────┴──────────────────┐
                  │  REST API: GET /api/v1/mailboxes/   │
                  │           {address}/messages        │
                  └─────────────────┬──────────────────┘
                                    │
                             Playwright test
                            polls → extracts → continues

The temporary inbox acts as a controllable endpoint on the SMTP receive side. You created it with one HTTP call; you read from it with another; you tear it down when the test is done. The application under test never knows the difference.

---

Setup

Install Playwright

npm install --save-dev @playwright/test
npx playwright install chromium

Environment Variables

# .env.test (never commit this)
UCT_API_KEY=uct_your_key_here
DEMO_BASE_URL=http://localhost:3000   # your app under test

Get your API key at uncorreotemporal.com. The free tier is sufficient for local development; for parallel CI pipelines use a paid key with higher inbox quotas.

Playwright Config

// playwright.config.ts
import { defineConfig } from "@playwright/test";

export default defineConfig({
  testDir: "./tests",
  timeout: 60_000,          // generous for email delivery
  workers: process.env.CI ? 4 : undefined,
  use: {
    headless: true,
    baseURL: process.env.DEMO_BASE_URL ?? "http://localhost:3000",
  },
});

---

Step-by-Step Implementation

Step 1 — Create an Inbox via API

The inbox is created before the browser even opens. It gives you a real email address that accepts SMTP delivery.

// tests/helpers/email.ts

const BASE = "https://uncorreotemporal.com/api/v1";

interface Inbox {
  address: string;
  expires_at: string;
  session_token: string;
}

export async function createInbox(ttlMinutes = 15): Promise<Inbox> {
  const res = await fetch(`${BASE}/mailboxes`, {
    method: "POST",
    headers: {
      "Content-Type": "application/json",
      "X-API-Key": process.env.UCT_API_KEY!,
    },
    body: JSON.stringify({ ttl_minutes: ttlMinutes }),
  });

  if (!res.ok) {
    throw new Error(`Failed to create inbox: ${res.status} ${await res.text()}`);
  }

  return res.json();
}

The response shape:

{
  "address": "crisp-falcon-77@uncorreotemporal.com",
  "expires_at": "2026-03-24T15:00:00+00:00",
  "session_token": "dGhpcyBpcyBhIHNhbXBsZSB0b2tlbg"
}

The session_token authenticates all subsequent calls to this inbox without requiring your API key in every request. Store it alongside the address.

---

Step 2 — Use the Inbox in the Signup Form

Nothing special here from Playwright's perspective — the address is just a string:

// tests/auth/signup.spec.ts
import { test, expect } from "@playwright/test";
import { createInbox, waitForEmail, deleteInbox } from "../helpers/email";

test("signup → email verification → dashboard", async ({ page }) => {
  const inbox = await createInbox();

  try {
    await page.goto("/register");
    await page.fill('[name="email"]', inbox.address);
    await page.fill('[name="password"]', "Secure1234!");
    await page.click('[type="submit"]');

    // App redirects to "check your email" page
    await page.waitForURL("**/confirm**");
    await expect(page.locator("h1")).toContainText("Check your email");

    // Now the SMTP delivery window opens — email is in transit
    const email = await waitForEmail(inbox.address, inbox.session_token);

    // ... extract and complete (shown in Steps 4–5)
  } finally {
    await deleteInbox(inbox.address, inbox.session_token);
  }
});

The try/finally pattern matters: the inbox is deleted even if the test throws halfway through.

---

Step 3 — Wait for the Email (Polling with Retry)

Transactional email in a staging environment typically arrives in under 5 seconds. Build a polling helper that respects a timeout and distinguishes network errors from "not arrived yet":

// tests/helpers/email.ts (continued)

interface MessageSummary {
  id: string;
  subject: string;
  from_address: string;
  received_at: string;
}

interface FullMessage extends MessageSummary {
  body_text: string | null;
  body_html: string | null;
  attachments: unknown[];
}

export async function waitForEmail(
  address: string,
  sessionToken: string,
  options: { timeout?: number; interval?: number; subjectFilter?: string } = {}
): Promise<FullMessage> {
  const { timeout = 30_000, interval = 2_000, subjectFilter } = options;
  const encoded = encodeURIComponent(address);
  const headers = { "X-API-Key": process.env.UCT_API_KEY! };
  const deadline = Date.now() + timeout;

  while (Date.now() < deadline) {
    let messages: MessageSummary[];

    try {
      const res = await fetch(`${BASE}/mailboxes/${encoded}/messages`, { headers });
      if (!res.ok) throw new Error(`HTTP ${res.status}`);
      messages = await res.json();
    } catch (err) {
      // Network error: retry, don't fail fast
      console.warn(`[waitForEmail] poll error: ${err}. Retrying...`);
      await sleep(interval);
      continue;
    }

    const match = subjectFilter
      ? messages.find((m) => m.subject.toLowerCase().includes(subjectFilter.toLowerCase()))
      : messages[0];

    if (match) {
      const res = await fetch(`${BASE}/mailboxes/${encoded}/messages/${match.id}`, { headers });
      if (!res.ok) throw new Error(`Failed to fetch message body: ${res.status}`);
      return res.json();
    }

    await sleep(interval);
  }

  throw new Error(`[waitForEmail] No email arrived at ${address} within ${timeout}ms`);
}

function sleep(ms: number) {
  return new Promise((r) => setTimeout(r, ms));
}

Key design decisions here:

• Network errors are retried, not propagated — a transient DNS hiccup shouldn't fail your test.
• "No message" means keep polling, not failure — email delivery has legitimate latency.
• subjectFilter lets you target the right email when your app sends both a welcome email and a separate confirmation. messages[0] on an inbox that received two messages is ambiguous.

---

Step 4 — Parse the Email (OTP and Link Extraction)

Both patterns come up in real apps. Handle them explicitly:

// tests/helpers/email.ts (continued)

/**
 * Extract a 6-digit OTP from email body.
 * Tries plain text first — it's cleaner to regex than HTML.
 */
export function extractOTP(message: FullMessage): string {
  const sources = [message.body_text, message.body_html].filter(Boolean) as string[];

  for (const content of sources) {
    const match = content.match(/\b(\d{6})\b/);
    if (match) return match[1];
  }

  throw new Error("OTP not found in email body");
}

/**
 * Extract a verification link matching the given URL prefix.
 * Falls back from HTML to plain text if needed.
 */
export function extractVerificationLink(message: FullMessage, urlPrefix: string): string {
  const pattern = new RegExp(`${escapeRegex(urlPrefix)}[^\\s"'<>]+`);
  const sources = [message.body_text, message.body_html].filter(Boolean) as string[];

  for (const content of sources) {
    const match = content.match(pattern);
    if (match) return match[0];
  }

  throw new Error(`Verification link not found in email body (prefix: ${urlPrefix})`);
}

function escapeRegex(s: string) {
  return s.replace(/[.*+?^${}()|[\]\\]/g, "\\$&");
}

One thing worth noting: when an OTP is embedded in an HTML button or styled table cell, body_text usually renders it cleanly as a bare number. Prefer body_text for numeric extraction, body_html only as a last resort.

---

Step 5 — Complete the Auth Flow in Playwright

OTP flow:

// Inside your test:
const email = await waitForEmail(inbox.address, inbox.session_token, {
  subjectFilter: "Your verification code",
});
const otp = extractOTP(email);

await page.fill('[name="otp"]', otp);
await page.click('[type="submit"]');
await expect(page.locator('[data-testid="dashboard"]')).toBeVisible();

Verification link flow:

const email = await waitForEmail(inbox.address, inbox.session_token, {
  subjectFilter: "Confirm your account",
});
const link = extractVerificationLink(email, `${process.env.DEMO_BASE_URL}/verify`);

// Navigate Playwright directly to the link — no need to simulate clicking
await page.goto(link);
await expect(page.locator("h1")).toHaveText("Account verified");

Using page.goto(link) instead of typing the link or clicking a button in the email is intentional. The email client is out of scope; you want to assert that the link works, not that the email renders correctly as a clickable element.

---

Full Working Example

Here is the complete spec file matching the structure of the temporary-email-api-examples repository, adapted to the production API:

// tests/auth/register.spec.ts
import { test, expect } from "@playwright/test";

// ── API helpers ──────────────────────────────────────────────────────────────

const BASE = "https://uncorreotemporal.com/api/v1";
const API_HEADERS = {
  "Content-Type": "application/json",
  "X-API-Key": process.env.UCT_API_KEY!,
};

async function createInbox(ttlMinutes = 15) {
  const res = await fetch(`${BASE}/mailboxes`, {
    method: "POST",
    headers: API_HEADERS,
    body: JSON.stringify({ ttl_minutes: ttlMinutes }),
  });
  if (!res.ok) throw new Error(`createInbox failed: ${res.status}`);
  return res.json() as Promise<{ address: string; session_token: string; expires_at: string }>;
}

async function waitForEmail(
  address: string,
  timeout = 30_000,
  subjectFilter?: string
) {
  const encoded = encodeURIComponent(address);
  const headers = API_HEADERS;
  const deadline = Date.now() + timeout;

  while (Date.now() < deadline) {
    const res = await fetch(`${BASE}/mailboxes/${encoded}/messages`, { headers });
    if (!res.ok) { await sleep(2_000); continue; }

    const messages: Array<{ id: string; subject: string }> = await res.json();
    const hit = subjectFilter
      ? messages.find((m) => m.subject.toLowerCase().includes(subjectFilter.toLowerCase()))
      : messages[0];

    if (hit) {
      const full = await fetch(`${BASE}/mailboxes/${encoded}/messages/${hit.id}`, { headers });
      return full.json() as Promise<{ body_text: string | null; body_html: string | null }>;
    }

    await sleep(2_000);
  }
  throw new Error(`No email at ${address} after ${timeout}ms`);
}

async function deleteInbox(address: string) {
  const encoded = encodeURIComponent(address);
  await fetch(`${BASE}/mailboxes/${encoded}`, { method: "DELETE", headers: API_HEADERS });
}

function extractOTP(body_text: string | null, body_html: string | null): string {
  for (const content of [body_text, body_html]) {
    if (!content) continue;
    const m = content.match(/\b(\d{6})\b/);
    if (m) return m[1];
  }
  throw new Error("OTP not found in email");
}

function sleep(ms: number) {
  return new Promise<void>((r) => setTimeout(r, ms));
}

// ── Test ─────────────────────────────────────────────────────────────────────

test("full signup → OTP → dashboard", async ({ page }) => {
  const inbox = await createInbox();

  try {
    // Step 1: Fill the signup form with the temp inbox address
    await page.goto("/register");
    await page.fill('[name="email"]', inbox.address);
    await page.click('[type="submit"]');

    // Step 2: App redirects to the OTP confirmation screen
    await page.waitForURL("**/confirm**");

    // Step 3: Wait for real email delivery
    const email = await waitForEmail(inbox.address, 30_000, "OTP");

    // Step 4: Extract OTP
    const otp = extractOTP(email.body_text, email.body_html);

    // Step 5: Submit OTP — complete the auth flow
    await page.fill('[name="email"]', inbox.address);
    await page.fill('[name="otp"]', otp);
    await page.click('[type="submit"]');

    await expect(page.locator("h1")).toHaveText("Welcome to the dashboard");
  } finally {
    await deleteInbox(inbox.address);
  }
});

Run it:

UCT_API_KEY=uct_your_key DEMO_BASE_URL=http://localhost:3000 npx playwright test

---

CI/CD Integration

GitHub Actions

# .github/workflows/e2e.yml
name: E2E Tests

on:
  push:
    branches: [main, staging]
  pull_request:

jobs:
  playwright:
    runs-on: ubuntu-latest
    timeout-minutes: 10

    env:
      UCT_API_KEY: ${{ secrets.UCT_API_KEY }}
      DEMO_BASE_URL: ${{ vars.STAGING_URL }}

    steps:
      - uses: actions/checkout@v4

      - uses: actions/setup-node@v4
        with:
          node-version: 20
          cache: npm

      - run: npm ci

      - name: Install Playwright browsers
        run: npx playwright install --with-deps chromium

      - name: Run E2E tests
        run: npx playwright test

      - uses: actions/upload-artifact@v4
        if: failure()
        with:
          name: playwright-report
          path: playwright-report/

Why This Beats Mocking in CI

The UCT_API_KEY secret is the only external dependency you add to the pipeline. There is no SMTP container to spin up, no shared state to coordinate between matrix jobs, no staging-only bypass flag to remember to flip off.

Each CI run creates inboxes that are:

• Isolated — parallel jobs cannot read each other's emails
• Deterministic — the inbox address is generated fresh every run; no state bleeds between runs
• Self-cleaning — the finally block deletes explicitly; TTL expiry cleans up if the job is killed

For a matrix strategy across multiple plans or regions, no changes are needed:

strategy:
  matrix:
    plan: [free, pro]
  fail-fast: false

Each matrix leg creates its own inbox. They run in parallel with zero coordination.

---

Best Practices

Use subjectFilter when your app sends multiple emails per registration. Welcome emails and confirmation emails arrive in the same inbox. messages[0] on a two-message inbox is a race you will lose eventually.

Distinguish network errors from missing emails in your polling loop. A 503 from the API should retry silently. A clean empty-array response with no messages after 30 seconds is a real failure. The waitForEmail helper above handles this by only retrying on non-2xx responses.

Set ttl_minutes to 5 in CI, 15 locally. Shorter TTLs reduce inbox accumulation if a test crashes before finally runs. In local development, 15 minutes gives you time to inspect the inbox manually if a test breaks.

One inbox per test(), not per describe(). Running two tests in the same describe block against a shared inbox breaks isolation. If test A registers and triggers a welcome email and a confirmation email, test B's waitForEmail might grab the wrong one.

Use Playwright's --shard flag for parallelism, not just workers. With four shards across four runners, 40 tests create 40 inboxes in parallel. The temporary email API is rate-limit-aware — add 200ms jitter to createInbox() calls if you're running very large suites.

// Add jitter to inbox creation in high-concurrency environments
await sleep(Math.random() * 200);
const inbox = await createInbox();

Log the inbox address on test failure. When a test times out waiting for an email, the inbox address is the key debug artifact. Playwright's test.info().annotations is a clean place to attach it:

test.info().annotations.push({ type: "inbox", description: inbox.address });

---

Why Real Email Testing Matters

The gap between a mocked email test and a real email test is not about coverage percentage — it's about what class of bugs each catches.

Bug	Mock catches	Real inbox catches
sendEmail() not called	Yes	Yes
Email template render failure	No	Yes
Broken verification link format	No	Yes
Wrong base URL for the environment	No	Yes
SMTP credential expiry	No	Yes
SPF / DKIM rejection causing silent drop	No	Yes
OTP in email doesn't match backend	No	Yes

The most painful production bugs are in the second column. A broken template, a link pointing to localhost, an SMTP key rotated without updating CI secrets — these are the bugs that reach users because the mocked test reported green.

Testing against real SMTP delivery does not require standing up your own mail server. Programmable Temporary Email Infrastructure — what uncorreotemporal.com provides — is designed exactly for this: a real inbox, reachable by real SMTP, provisioned in one HTTP call, and expired automatically when the test is done.

Your E2E tests should exercise the same delivery path your users rely on. If they don't, you're flying blind on one of the most common points of failure in user registration.

---

Try It

If you want to run this yourself, the complete working examples — including the demo Express app that the Playwright tests use as the application under test — are in the temporary-email-api-examples repository.

Get your API key and start testing real email flows at uncorreotemporal.com.
